SIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG Welder

05751

SIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG WelderSIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG Welder
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.
Product thumbnail.

The SIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG Synergic Welder is a multi-process inverter welder specifically designed for use in automotive and garage environments.

Fully compliant with Reg EU 2019/1784 (Eco Design for Welding Equipment), this welder features a 4th generation inverter which is above 80% energy efficient. This means it uses less power at the same output as older inverters, helping to lower operational costs.

It also includes Pure Synergic Control, which allows users to adjust welding voltage and wire feed speed autonomously. This simplifies the welding process at all skill levels and helps to achieve more consistent and higher quality welds.

KEY FEATURES

  •  Multi-process MIG/ARC/TIG welder for greater welding flexibility at high duty cycles
  •  Features Pure Synergic Control for more consistent and higher quality welds
  •  Fully compliant with Reg EU 2019/1784 (Eco Design for Welding Equipment)
  •  Heavy-duty cast aluminium 2-roll wire feeder for smooth consistent flow of wire
  •  Intuitive control panel to select between welding processes and function settings
  •  Wheel-mounted design with lockable front castors for mobility around work area

   SIP 2-Year Standard Silver Warranty* | Find out more

Full Specification

The SIP WELDMATE® AUTOPLUS 250A MIG/ARC/TIG Synergic Welder is a multi-process inverter welder specifically designed for use in automotive and garage environments.

Fully compliant with Reg EU 2019/1784 (Eco Design for Welding Equipment), this welder features a 4th generation inverter which is above 80% energy efficient. This means it uses less power at the same output as older inverters, helping to lower operational costs.

It also includes Pure Synergic Control, which allows users to adjust welding voltage and wire feed speed autonomously. This simplifies the welding process at all skill levels and helps to achieve more consistent and higher quality welds.

Applications & uses: Ideal for automotive and garage environments. Suitable for MIG/ARC/TIG welding and performs gasless MIG welding. Perect for sheet metal applications. Ideal for mild steel.

SIP 2-Year Standard Silver Warranty* | Find out more

Full Specification 2

MULTI-PROCESS MIG/ARC/TIG WELDER FOR GREATER FLEXIBILITY AT HIGH DUTY CYCLES

  • Duty cycle @ 20°C: 250A @ 80% (MIG/ARC/TIG).

PURE SYNERGIC CONTROL ALLOWS USERS TO ADJUST THE WELDING VOLTAGE & WIRE SPEED AUTONOMOUSLY

  • This easy-to-set function simplifies the welding process at all skill levels, helping to achieve more consistent and higher quality welds.

HEAVY-DUTY CAST ALUMINIUM 2-ROLL WIRE FEEDER ENSURES SMOOTH & CONSISTENT FLOW OF WIRE TO MIG TORCH

  • This easy-to-use device includes tension adjustment to maintain optimal performance.
  • Supplied with interchangeable feed rollers for solid and flux-cored wires.
  • Compatible with welding wire spools of 5kg and 15kg.
  • Fitted with a welding torch Euro connector and supplied with a 3mtr Euro MIG torch.

INTUITIVE CONTROL PANEL TO SELECT BETWEEN WELDING PROCESSES & SETTINGS

  • This also includes MIG torch settings, gas type and wire size selector, 'Synergic' control function, 'Inductance' to control and reduce weld spatter, 'Wire Inch' to feed torch wire without using gas, and 'ARC Force' for fine arc adjustment.
  • Infinitely variable dials offer a smoothless stepless output adjustment for higher quality and easy to control welding.
  • Twin LEDs display welding outputs and synergic control metrics.

WHEEL-MOUNTED DESIGN FOR MOBILITY AROUND THE WORK AREA & SUITABLE FOR GAS CYLINDER UP TO 99KG

  • Fitted with lockable front castors and large rear wheels for easy movement around the work area.
  • Includes retaining straps for securing gas cylinder to the rear of the welder.
  • Fitted with rotary power switch.
  • High-quality finish is resistant to work area damage. Control panel cover for added protection.

ACCESSORIES INCLUDED

  • Supplied with a 3mtr Euro MIG torch, electrode lead, earth lead, gas hose with clamps, contact tips and wire feed rollers.

Product Video



Technical Information

ITEM NO. 05751
Input Supply: 230v (32A)
Welding Process: MIG ARC TIG
Output Voltage: 15.5v - 26.5v 21.2v - 30v 10.4v - 20v
Output Current: 30A - 250A 30A - 250A 10A - 250A
Duty Cycle @ 20°C: 250A @ 80% 250A @ 80% 250A @ 80%
Wire Diameter: ⌀ 0.8mm - 1.2mm
Wire Spool Size: 5kg, 15kg
Welding Material Thickness: 0.8mm - 6.4mm (mild steel)
Protection / Insulation 21S / H
Net Weight: 40kg
Gross Weight: 43kg
Product Dimensions: 650(H) x 450(W) x 880mm(D)
Packaged Dimensions: 620(H) x 400(W) x 670mm(D)

Documentation

PRODUCT DOCUMENTATION

Click below to access any documentation currently available for this product.

DOWNLOAD HERE

Warranty Information



COMES WITH A 2 YEAR STANDARD WARRANTY*

NOW AVAILABLE ON ALL SIP MACHINES!

SIP products offer exceptional durability, reliability, and heavy-duty performance. All of our machines are underpinned by the SIP 2-Year Standard Silver Warranty*. In addition to this, we offer a service-based Gold Warranty that extends your cover for a further 2 years when purchased.

All SIP Premium Partner Brands offer comprehensive warranties of their own!

*Excludes accessories and consumables.
